Three Phase Hoists
As one of Australia’s leading jib crane suppliers, Total Lifting Solutions can supply you with high-quality wall mounted or portable jib cranes for sale that will get the job done. Our team of certified jib crane manufacturers have the experience and skills required to design and build the most advanced jib cranes Australia has to offer.
ER electric hoists are manufactured to a lightweight, compact design in capacities ranging from 250 kg to 20 tonnes. Featuring a single die-cast aluminium body and world class reduced headroom, the ER range provides improved operational efficiency, easier maintenance and unparalleled safety standards.
Single Speed
(415v-3-50)
Capacity | Part No | Model | Lift Speed | Headroom |
(m/min) | (mm) | |||
250kg | 43001 | ER003S | 9.7 | 350 |
500kg | 43002 | ER005L | 3.7 | 355 |
500kg | 43003 | ER005S | 7.6 | 370 |
1 tonne | 43004 | ER010L | 3.9 | 415 |
1 tonne | 43005 | ER010S | 7.3 | 440 |
1.5 tonne | 43006 | ER015S | 5.1 | 520 |
2 tonne | 43007 | ER020L | 3.6 | 560 |
2 tonne | 43008 | ER020S | 7.1 | 610 |
2.5 tonne | 43009 | ER025S | 5.7 | 625 |
3 tonne | 43010 | ER030L | 4.1 | 660 |
3 tonne | 43011 | ER030S | 5.6 | 660 |
5 tonne | 43012 | ER050L | 2.9 | 835 |
NOTE: All ER Electric Hoists fitted with overload clutch along with dust and water jet proof body (IP55 rating)
Part numbers shown for standard lift models (3 metres), optional lift heights available
Dual Speed
(415V-3-50)
Capacity | Part No | Model | Lift Speed | Headroom |
(m/min) | (mm) | |||
250kg | 43021 | ER003SD | 7.2/2.4 | 350 |
500kg | 43022 | ER005LD | 3.6/1.2 | 355 |
500kg | 43023 | ER005SD | 7.6/2.5 | 370 |
1 tonne | 43024 | ER010LD | 3.6/1.2 | 415 |
1 tonne | 43025 | ER010SD | 7.3/2.4 | 440 |
1.5 tonne | 43026 | ER015SD | 5.1/1.7 | 520 |
2 tonne | 43027 | ER020LD | 3.7/1.2 | 575 |
2 tonne | 43028 | ER020SD | 7.2/2.4 | 685 |
2.5 tonne | 43029 | ER025SD | 5.8/1.9 | 685 |
3 tonne | 43030 | ER030LD | 4.1/1.4 | 725 |
3 tonne | 43031 | ER030SD | 5.8/1.9 | 725 |
5 tonne | 43032 | ER050LD | 2.9/1.0 | 895 |
NOTE: All ER Electric Hoists fitted with overload clutch along with dust and water jet proof body (IP55 rating)
Part numbers shown for standard lift models (3 metres), optional lift heights available
